BF 6 M 1015 C

Water-cooled 6-cylinder V-engine.
Turbocharging with charge air cooling.
Four-valve technology.
Injection system with mechanical governor, mechanically actuated/electronically controlled high-pressure injection on request.
Separate gear-driven PTOs, beltless fan drive.
Powerful and rugged engine with a high power-to-volume ratio.
Very compact design.

Technical data
Emission norms EU II, US T2
Number of cylinders 6
Bore 132 mm5.2 in
Stroke 145 mm5.7 in
Displacement 11.9 l726 cu in
Maximum nominal speed 2100 rpm
Power output 300 kW402 hp
at speeds 2100 rpm
Max. torque 1978 Nm1459 lb/ft
at speeds 1200 rpm
Min. idling speed 550 rpm
Specific fuel consumption 203 g/kWh0.33 lb/hph
Length 841 mm33.1 in
Width 932 mm36.7 in
Height 1170 mm46.1 in
Weight 850 kg1874 lb
Download data sheet (PDF-file)
